3-Axis Vibration Testing System 10kN for Lithium-Ion Batteries

3-Axis Lab Equipment Vibration Testing System for Lithium-Ion Battery Testing

Our 3-Axis Lab Equipment Vibration Testing System is a cutting-edge solution specifically engineered to meet the demanding safety and performance standards for Lithium-Ion Battery Testing. This advanced system subjects batteries to simultaneous vibration along the X, Y, and Z axes, providing a highly realistic and comprehensive simulation of complex, multi-directional stresses encountered during transportation and operation. It's an indispensable tool for R&D labs, certification bodies, and quality assurance teams dedicated to ensuring the mechanical integrity and safety of lithium-ion batteries and their components.

Key Features

• True 3-Axis Simultaneous Vibration: Capable of generating complex vibration profiles along the X, Y, and Z axes at the same time, accurately replicating real-world dynamic loads and uncovering multi-directional weaknesses.

• Optimized for Battery Safety Standards: Configured to meet and exceed key international standards for battery testing, including UN 38.3, IEC 62133, and SAE J2380, ensuring compliance for global market access.

• Precision Electrodynamic Shaker Technology: Provides accurate, repeatable, and controlled generation of complex vibration profiles including sine, random, and shock, crucial for fulfilling specific battery safety and durability requirements.

• Advanced Multi-Axis Digital Control System: Our powerful, intuitive controller seamlessly manages all three axes of vibration, allowing for precise programming and execution of complex test sequences with exceptional stability and accuracy.

• Integrated Safety Protocols: Includes multiple safety interlocks, over-travel protection, emergency stops, and features vital for the safe handling and testing of lithium batteries, such as optional inert gas purging and fire suppression systems.

• Comprehensive Data Acquisition: Continuously monitors and records all vibration data, along with optional battery-specific data (e.g., voltage, temperature, current), for in-depth analysis, root cause identification, and auditable compliance reports.

• Lab-Grade Footprint: Designed with an optimized size and minimal noise output, making it suitable for laboratory and R&D environments without compromising on performance.

• Customizable Test Fixtures: Our engineering team designs and manufactures application-specific fixtures to securely mount diverse battery configurations, from individual cells to large packs, ensuring proper vibration transmission and test integrity.

Applications

• UN 38.3 Transportation Compliance: Fulfilling the multi-axis vibration requirements for the safe global transport of lithium-ion batteries.

• EV Battery Pack & Module Validation: Simulating the complex 3D road vibration and impact stresses on battery systems for electric vehicles.

• Energy Storage Systems (ESS): Evaluating the durability of battery components used in grid-scale energy storage under multi-directional seismic and operational stresses.

• Wearable Electronics & IoT Devices: Ensuring the mechanical integrity of small, lightweight batteries in consumer and industrial products.

• Research & Development: Accelerating the development of new battery chemistries and pack designs by understanding their behavior in multi-stress, real-world environments.

• Quality Assurance & Failure Analysis: Implementing rigorous testing to screen for manufacturing defects and identify potential failure modes early in the product lifecycle.

Benefits

• Unmatched Test Realism: Provides the most accurate and comprehensive assessment of battery performance by simulating true multi-directional stresses, revealing weaknesses missed by single-axis testing.

• Enhanced Safety & Reliability: Proactively identifies and mitigates critical safety risks, such as internal shorts or structural failures, ensuring batteries perform flawlessly in the field.

• Accelerated R&D: Dramatically reduces development cycles by quickly validating new designs against complex, worst-case scenarios.

• Guaranteed Regulatory Compliance: Facilitates adherence to international standards, providing a clear path to global market access.

• Comprehensive Data Insights: Generates rich, synchronized data for in-depth analysis, contributing to superior design optimization and robust validation reports.

•
